Guide – How to: design a single-core SoC

Latest update: 2023-02-22

This guide illustrates how to generate and test a minimal single-core ESP SoC. In doing so, this tutorial covers the basics of SoC configuration, full-system RTL simulation and FPGA prototyping with the ESP platform.

• Target FPGA board
• SoC configuration
• Debug link configuration
  • a) Direct link
  • b) Link through a router
• ESP Cache Hierarchy
• Optional: HLS-Based Cache Hierarchy
• RTL simulation
• FPGA prototyping
  • Bitstream
  • Bare-metal and Linux applications
  • FPGA programming
  • UART interface
  • Testing on FPGA
  • SSH
• FPGA prototyping with prebuilt material

Note: The users have access to prebuilt material to run the tutorial on an FPGA, without executing all the previous steps. See the ‘FPGA prototyping with prebuilt material’ section at the end of this guide.

Target FPGA board

ESP currently supports multiple FPGA boards as listed in the homepage. The socs/ directory of ESP contains a working folder for each of the target FPGA boards. The steps described in this guide are identical for all the FPGA targets, but they should be run from the working folder in socs/ corresponding to the desired target.

For this tutorial we target the popular Xilinx VC707 evaluation board based on the Virtex7 FPGA.

# Move to the Xilinx VC707 working folder
cd <esp>/socs/xilinx-vc707-xc7vx485t

Running make help in the working folder prints a description of the most common Make targets in ESP, many of which are described in this tutorial.

Back to top

SoC configuration

Each working folder comes with a default SoC configuration (socs/defconfig/esp_<working-folder-name>_defconfig), which consists of a 2x2 mesh with one processor tile, one memory tile containing a memory controller and one auxiliary tile. This is the minimum set of tiles for a functioning ESP SoC. Depending on the working folder the default configuration may differ in the processor core selection (e.g. RISC-V Ariane or SparcV8 Leon3) and in the presence of the ESP cache hierarchy.

The SoC configuration can be visualized and modified with the ESP configuration GUI:

make esp-xconfig

The figure below shows the GUI with the default configuration for the Xilinx VC707 board. In this case the selected CPU is the Leon3 processor and the ESP caches are enabled: one 32KB 4-ways set associative private L2 cache for the processor tile and one 256KB 16-ways set associative last-level cache (LLC) on the memory tile. In this design the LLC serves only the processor tile and the Ethernet MAC in the miscellaneous (IO) tile.

Back to top

Debug link configuration

A host machine communicates with an ESP SoC through an Ethernet debug interface. As shown below, the static IP of the debug interface can be configured by editing the IP and MAC addresses in the Debug Link section of the ESP GUI.

There are two possible ways to access an ESP SoC on FPGA through Ethernet from a host machine: with a direct link or through a router. In the following, as an example, we assume you set the IP address of the debug link to 192.168.1.2 (C0A80102 in hex).

Back to top

a) Direct link

Connect with an Ethernet cable the Ethernet ports of FPGA and of the host computer that you wish to interact with the ESP SoC on FPGA. From your system settings, turn off the wired internet connection. Then, from a terminal, assign a valid IP address to your interface using the same three numbers of the ESP debug link (192.168.1 in this example) and varying the last one. This guarantees that your host machine will be in the same subnet as the ESP debug link, so that it will be possible to establish a connection between the two.

In this example we assume your Ethernet interface name is eth0. (You can find out the specific name of the interface by typing ifconfig in your shell.)

# assign an IP address to your host machine
sudo ifconfig eth0 192.168.1.3

Back to top

b) Link through a router

With two Ethernet cables, connect the Ethernet ports of both your FPGA board and your host computer to a router. The IP address assigned to the ESP debug link must be in the subnet selected by the router. For instance, if the router assigns IP addresses in the range 192.168.1.2 to 192.168.1.255, then any IP address in that range can be used for the ESP debug link. From the admin webpage of the router you should be able to change the range of assigned addresses, as well as to reserve a specific IP to the MAC address corresponding to the ESP debug link. Reserving the IP will guarantee that no other device connected to the router will get the IP of the debug link through a DHCP request.

In case your host computer received the same IP you selected for the debug link, you can force a new lease with the following:

# assign an IP address to your host machine
sudo ifconfig eth0 192.168.1.3

It is, however, recommended to reserve the IPs from the router’s admin page rather than forcing the IP assignment from the host computer.

Back to top

ESP Cache Hierarchy

With a single-core SoC, you have the option of using ESP’s cache hierarchy, which adds a private L2 cache to CPUs (and optionally, to accelerators) and a last-level cache to the memory tile (the LLC is partitioned if multiple memory tiles are selected). The checkbox labeled Use Caches enables the cache hierarchy, which is the default setting. There are two options for the implementation of the caches – SystemVerilog and ESP HLS – which can be selected from the dropdown menu labeled Implementation in the ESP configuration GUI. The SystemVerilog caches ESP RTL offer area savings and slight timing improvements and is the default.

Note that with the SystemVerilog implementation , the CPU L2 and accelerator L2 caches must be configured to have the same number of sets and ways. For more information on the HLS-based cache hierarchy, read the section below.

Back to top

Optional: HLS-Based Cache Hierarchy

As shown above, the default SoC for the Xilinx VC707 board has the ESP cache hierarchy enabled. By default, the RTL implementation is selected. If you want to switch to the SystemC version, select SystemC + HLS from the Implementation dropdown in the ESP configuration GUI. This feature is particularly useful to conduct architectural research on coherence, because the SystemC model is significantly easier to edit than the RTL implementation.

To generate the RTL for the SystemC version of the caches, a one-time HLS run is required for every desired combination of sets and ways of the caches.

make l2-hls
make llc-hls

These commands run HLS with Cadence Stratus HLS for all the combinations of {sets, ways, words per line, word bitwidth, address bitwidth} specified in HLS TCL scripts: rtl/caches/esp-caches/systemc/l2/stratus/project.tcl, rtl/caches/esp-caches/systemc/llc/stratus/project.tcl. The first HLS run takes a long time, because it synthesizes hardware resources from scratch, whereas the subsequent HLS runs are much faster.

The ESP cache hierarchy is mandatory only for multi-core ESP SoCs. If the caches are not enabled in the ESP configuration GUI, or if using the RTL implementation, this step can be skipped.

Back to top

RTL simulation

Users can run a full-system RTL simulation with the following targets:

# Modelsim
make sim[-gui]

# Incisive
make ncsim[-gui]

# Xcelium
make xmsim[-gui]

Once Modelsim starts you can launch with the simulation with the command:

make run --all

These simulation targets compile the RTL from ESP and from some Xilinx libraries. In addition to RTL files, the simulation targets cross-compile the default C application systest.c for the target processor. Then the simulator starts either in the terminal (e.g. make sim) or with the GUI (e.g. make sim-gui).

Users can edit systest.c at will, as long as the baremetal cross-compiler can generate the target binary. The output of this compilation are the memory files for simulation (prom.srec and ram.srec) and the target binaries for FPGA emulation of the baremetal test (prom.bin and systest.bin). These outputs are generated at the path soft-build/<cpu> in the working folder, where in this case the target CPU is leon3.

Users can run the software compilation step independently from the simulation target with:

make soft

Back to top

FPGA prototyping

Bitstream

The deployment of an ESP SoC on FPGA requires a FPGA bitstream, whereas its testing requires the binary of a baremetal application and/or a Linux image.

Below is the target to generate the FPGA bitstream with Xilinx Vivado from the working folder based on what specified in the GRLIB and ESP configurations. After Vivado completes the bitstream generation, a link to the bitstream top.bit is created in the SoC working folder.

# Logic synthesis for FPGA with Xilinx Vivado
make vivado-syn

Back to top

Bare-metal and Linux applications

The binary of the baremetal application (prom.bin and systest.bin) is compiled with make soft as described in the previous section.

Linux is also compiled from the ESP SoC folder. This allows users to maintain different Linux configurations and root filesystem overlays for each SoC folder. The following command configures and compiles Linux with the root filesystem template created with the scripts to build the toolchain. Users can add, edit or remove files from the local copy of the filesystem placed in soft-build/<cpu>/sysroot/. Re-running the Linux target below will update the embedded root file system. The final output of this target is a bootable Linux image (soft-build/<cpu>/linux.bin).

make linux

Back to top

FPGA programming

Assuming the FPGA host computer is localhost and the TCP port is the default 3121, the ESP instance can be deployed on FPGA with the following command:

# Program FPGA
FPGA_HOST=localhost XIL_HW_SERVER_PORT=3121 make fpga-program

If you are using a remote FPGA device and the JTAG cable is connected to a remote host computer, set FPGA_HOST and XIL_HW_SERVER_PORT to the appropriate values. The remote server must be running an instance of Vivado hw_server.

Back to top

UART interface

After programming the FPGA, the ESP UART interface must be opened with a serial communication program (e.g. minicom) to monitor the programs executing on the ESP instance.

With the USB cable provided by the FPGA board vendor, connect the UART port to any USB port on your computer. Then run dmesg to find the device name assigned to the new serial interface. Here is an example:

$ dmesg | grep tty
[352854.825049] usb 1-2: cp210x converter now attached to ttyUSB0

For instance, if your serial interface has been labeled ttyUSB0, you may connect to /dev/ttyUSB0 with your favorite serial communication program. In this example we will refer to Minicom. The serial interface should be configured to use no parity bits, no flow control and a baud rate of 38400. To configure Minicom launch it with sudo minicom -s.

 +-----------------------------------------+
 |     Serial Device      : /dev/ttyUSB0   |
 |  Lockfile Location     : /var/lock      |
 |    Callin Program      :                |
 |   Callout Program      :                |
 |     Bps/Par/Bits       : 38400 8N1      |
 |  Hardware Flow Control : No             |
 |  Software Flow Control : No             |
 +-----------------------------------------+

Now you can launch Minicom:

minicom -D /dev/ttyUSB0 -b 38400

Please note that standard users on Linux do not have permission to connect to a serial interface. You can launch your terminal with sudo, or add yourself to the dialout group. Then you must log out in order for the group change to take effect.

sudo usermod -aG dialout <USERNAME>

Back to top

Testing on FPGA

Finally here are the commands to connect to the ESP SoC on FPGA and either run a baremetal program or boot Linux. Make sure to define FPGA_HOST and XIL_HW_SERVER_PORT also in this case or edit their value in the local Makefile of the working folder you working into.

# Run bare-metal program (systest.bin)
make fpga-run

# Run Linux (linux.bin)
make fpga-run-linux

The make fpga-run-linux command also runs the make fpga-program target as a dependency, so you don’t need to run it explicitly. To login into Linux use root as username and openesp as password. The latter is set by buildroot when the template for the root file system is generated (see the How to: setup guide).

Back to top

SSH

Once Linux boot has complete, it is possible to use SSH to access ESP remotely, as well as to move data to and from the ESP SoC on FPGA.

The IP address is printed on the serial console at the end of the boot process: udhcpc: lease of <esp-ip-address> obtained. Alternatively, you can get the network interface configuration and IP address with ifconfig

From a machine in the same network as the ESP instance on FPGA, you can use ssh or scp and pass the dynamic IP leased at the end of the Linux boot.

touch file_to_transfer
scp file_to_transfer root@<esp-ip-address>:~
ssh root@<esp-ip-address>

From the ESP Linux terminal you can use ssh and scp commands as in these examples:

touch file_to_transfer
ssh <username>@<host-static-ip>
scp file_to_transfer <username>@<host-static-ip>:~

Back to top

FPGA prototyping with prebuilt material

With the provided prebuilt material, the users can run the tutorial on FPGA directly, without the need for all the configuration, compilation and synthesis steps. We normally provide the prebuilt set, where the name of each tar.gz folder specifies the FPGA target board and the processor core used.

Here is a list of the prebuilt files, their description and the path where to place them inside the ESP repository:

• For the Xilinx VC707 board <fpga-board>=xilinx-vc707-xc7vx485t. For the Xilinx VCU118 board <fpga-board>=xilinx-vcu118-xcvu9p. For the Xilinx VCU128 board <fpga-board>=xilinx-vcu128-xcvu37p.

  • top.bit: FPGA bitstream. Place this file in socs/<fpga-board>/vivado/esp-<fpga-board>.runs/impl_1/.

  • systest.bin, prom.bin: bare-metal “Hello ESP!” application and Leon3 boot loader. Place these files in socs/<fpga-board>.

  • linux.bin: Linux image which includes the root file system. Place these files in socs/<fpga-board>.

After placing the prebuilt files in the right folders, follow the Debug link configuration instructions above. The ESP debug link in the prebuilt bitstream has IP 0xC0A80102 (192.168.1.2) and MAC 0x535522F00707 for the VC707 and VCU118 boards and IP 0xC0A8010C (192.168.1.12) and MAC 0xA6A7A0F80442 for the VCU128 board. Set them appropriately in the Grlib configuration GUI and save. The debug link is described above in the Debug link configuration section.

Note: the configuration of the MAC and IP address pairs in the latest version of ESP on Git may differ from the values set for the prebuilt material.

Finally, to run the tutorial on the FPGA you only need some of the steps described in the previous section: FPGA programming, UART interface, Testing on FPGA, SSH.
